- 2.5" Mandrel Bent Steel Piping
- SS T-Bolt Clamps
- Bolts to Existing Holes on Vehicle
- Short Route Piping for quick spool up
- Eliminates Knock at high boost levels
- Modular design allows for upgrade to single turbo with one pipe
- Battery and Radiator stays in stock location
Installation Details:
- Short Route Piping for quick spool up
- Works with factory T/B Elbow
- No need to relocate Radiator or Battery
- Fits Many turbo kits such as ETS, Greddy, Turbo XS, SFP, Apexi, etc.
- Requires Bumper Support Removal and Core Support Cutting
- Very Clean Set up
Exterior Appearance Details:
- Work with USA and JDM fog lights
- Killer Look !
Our Standard Single and Twin Turbo kit includes 2.5" Piping from turbo to throttle body elbow. If you are using a Greddy Elbow on the throttle body side you will need to use our 3" Greddy Elbow Pipe on the driver side. We do have the option to upgrade both long engine compartment pipes to 3" but only for cars equipped with the Greddy Elbow AND Single Turbo. The 2 Short pipes that connect to the intercooler and intercooler inlet/outlet remain 2.5".
Upgrading to Single from Twin Turbos: To Upgrade to Single turbo you will need to purchase a new Single Turbo upgrade Pipe (found in piping section) and a 2.5" 90 Degree Silicone Elbow.
Performance
The performance of this unit is second to none. We developed it on our shop car (yellow FD in the pictures) which runs a T66, Haltech and all other supporting mods. When we first put the car together it had an Apexi FMIC kit on it we saw decent results but the charge air temps would creep up to 140-150 degrees. Slight detonation would occur in 3rd, 4th and 5th gears as observed on the J&S Knock sensor unit. Also because the tanks were wide and the core was small, the coolant temps were regularly over 210 degrees. All of this was with a pump gas tune at 21psi (10.5 AFR 10 degrees ignition timing). When we switched to the kit pictured above the charge air temperatures dropped to 110 degrees and the highest we have ever seen is 122 degrees. This reduction in charge air temperature has allowed us to run 23psi regularly on pump gas with no detonation. In addition to the reduced charge air temperatures, the coolant temps dropped to 185-195 degrees and never exceed 200 degrees. All of this is with a stock bumper. We have had a handful of customer cars with body kits that see even larger temp reuctions. Typical results for a T66 turbo at 20psi is 95-110 degree charge air temperatures and 180-185 degree coolant temperatures. In addition to the low temperatures these kits provide, the ETS intercooler kit completely fills the stock bumper opening with core and body kits much better than any other kits we have seen with it s ultra wide 30 tank to tank dimension.
Aside from axleback/catback exhausts, clamps & couplers, and ETS Merchandise; we are unable to ship directly into California. These parts will likely need to ship to our location first and then out to you. Additional shipping charges will apply.
*Anodized intercoolers may take about 4-5 weeks, as the anodizing process is outsourced to a third-party company.
*Titanium pipes may take up to 3-4 weeks to ship if they are not in stock.
