Integrated Engineering IE Audi B9 SQ5 3.0T Carbon Fibre Intake System

Usually ships within 24 hours

$1,091.99

Color

Stock Turbo TTE710 Hybrid Turbo GTX35R Hybrid Turbo

Product details

Vendor Integrated Engineering
SKU IEINCZ1

Do you have questions about this product?

Ask an expert!

Description

IE's carbon fibre intake system for your B9 SQ5 is meticulously designed to improve turbo & engine efficiency and engineered for significant airflow gains on stock and hybrid turbochargers while keeping IATs to a minimum. Unique motorsport features produce power gains of up to 19HP & 21ft-lbs on tuned engines, making it the ultimate intake system that delivers style, sound, and power for your turbocharged SUV.

You also wish to purchase the optional Integrated Engineering IE Audi B9 SQ5 3.0T Turbo Inlet Pipe.

Features

High-gloss genuine carbon fiber construction
Leak-free seamless 1-piece airbox
Up to 19HP & 21ft-lbs over stock (with IE turbo inlet)
Flow 28% more than the stock intake system
Flow 44.2% more than stock intake (with IE turbo inlet)
Enhanced turbo & engine sound
High pressure & low pressure air zones
Maximized turbo & engine efficiency
Huge 5" air filter & velocity stack for excellent laminar flow
Factory style mounts for reliable & easy installation
All stainless hardware
Multi-ply silicone with stop-flat edges
High-quality clamps
Powder-coated aluminum filter plate
Stainless laser-etched logo plate

Integrated Engineering IE Audi B9 SQ5 3.0T Carbon Fibre Intake System - ML Performance US

Carbon Fibre - More Than Style

Carbon fibre allows our engineers to create complex shapes and angles to maximize internal volume while maintaining high resistance to heat. This design practice utilizes every millimeter available in the engine bay, providing a much larger air supply and smooth flow.

Integrated Engineering IE Audi B9 SQ5 3.0T Carbon Fibre Intake System - ML Performance US

Seamless Design

Our unique 1-piece airbox design offers a seamless and beautiful look without chances of air leaks, finicky installation, rubbing noises, or parts working loose over time, common with multi-peace airbox designs.

Integrated Engineering IE Audi B9 SQ5 3.0T Carbon Fibre Intake System - ML Performance US

Built-in Velocity Stack

The built-in velocity stack smoothly reduces airflow from the massive 5" air filter down to the turbo inlet with excellent laminar properties. This transition creates a very high inertia flow from the huge filter with very low drag or power-robbing turbulence.

Integrated Engineering IE Audi B9 SQ5 3.0T Carbon Fibre Intake System - ML Performance US

Multiple Pressure Zones

The intake takes advantage of multiple air supply avenues to support any power level. The front large air inlet receives outside high-pressure flow from the front of the grille and acts as a ram air design for most of the air supply. Additionally, the filter plate louvers pull extra required air from the low-pressure zone under the intake. These dual zones provide a free air supply across the entire filter and ensure your intake will never be a power limiter for even the most extreme builds.

Integrated Engineering IE Audi B9 SQ5 3.0T Carbon Fibre Intake System - ML Performance US

Unique Sound

Your sporty SUV is equipped with a 6-cylinder turbocharged engine -sound like one!

The factory airbox is designed to mute all engine and turbo sounds. When upgrading to an IE intake system, you will instantly become addicted to the new turbocharger spool, engine throttle, and diverter valve symphony under the hood. Your SQ5 won't only pull harder, it will also sound classy, refined, and powerful.

Integrated Engineering IE Audi B9 SQ5 3.0T Carbon Fibre Intake System - ML Performance US

Optional Turbo Inlet

Upgrading your intake with an IE cast turbo further removes significant airflow restrictions and maintains the largest size possible from the intake to the turbocharger. This combination increases flow from 28% (intake only) up to 57.6% over the stock intake and turbo inlet!Â

Turbo inlet pipe is an optional upgrade and can be purchased with your intake or added at a later date.

You can purchase the turbo inlet here:Â

Integrated Engineering IE Audi B9 SQ5 3.0T Turbo Inlet Pipe

Precision Fit

3D scanning tools are leveraged to create a digital duplicate of the vehicle's engine bay, grille, bumper, and hood. These high-resolution scans provide a digital environment that allows our engineers to take advantage of all available space while ensuring a perfect fit.

Integrated Engineering IE Audi B9 SQ5 3.0T Carbon Fibre Intake System - ML Performance US

Performance Gains

ONE-PIECE CARBON FIBRE CONSTRUCTION
UP TO +19HP & 21TQ POWER YOU CAN FEEL
FLOW OPTIMIZED VELOCITY STACK MOTORSPORT DESIGN

Power Results

Every inch of IE's intake system evolved from countless design revisions, rapid prototyping, flow bench testing, dyno runs, and real-world verification to maximize airflow and performance. The result is an intake system with power gains of up toÂ 19WHPÂ andÂ 21ft-lbsÂ of torque, with even higher gains possible on hybrid turbo setups! Â

Integrated Engineering IE Audi B9 SQ5 3.0T Carbon Fibre Intake System - ML Performance US

Flow Bench Testing

The proof is in the testing. Back-to-back flow bench results show constant and consistent CFM gains of up toÂ 44.2%Â CFMÂ over stock! This increase in flow details the intake design's efficiency over the factory parts and capability to provide any required airflow demands from ECU tunes and hybrid turbocharger upgrades.

Integrated Engineering IE Audi B9 SQ5 3.0T Carbon Fibre Intake System - ML Performance US

Flow Report

The following report details the above graph proving the efficiency gain of our performance intake system on the stock turbo.

-IN. H20	STOCK INTAKE	IE INTAKE & STOCK INLET	IE INTAKE & IE INLET
-5	129 CFM	165 CFM	186 CFM
-10	198 CFM	236 CFM	268 CFM
-15	250 CFM	292 CFM	333 CFM
-20	291 CFM	345 CFM	384 CFM
-25	330 CFM	383 CFM	430 CFM
-30	364 CFM	420 CFM	474 CFM

	IE INTAKE & STOCK INLET	IE INTAKE & IE INLET
MAXIMUM INCREASE:	+28% @ -5 in. H20	+44.2% @ -5 in/H20

Hybrid Turbo Flow Report

Upgrading to a hybrid turbocharger demands even more airflow. This flow result represent IEâ€™s intake and inlet upgrades with a hybrid turbo.

-IN. H20	STOCK INTAKE	IE INTAKE & IE INLET
-5	129 CFM	200 CFM
-10	198 CFM	312 CFM
-15	250 CFM	386 CFM
-20	291 CFM	447 CFM
-25	330 CFM	504 CFM
-30	364 CFM	553 CFM

	IE INTAKE & IE INLET
MAXIMUM INCREASE:	+57.6% @ -10 in. H20

The above gains are a result of various design details:

The 5" air filter surface area and increased air volume improve turbo efficiency.
The internal velocity stack provides a low-turbulence transition from the filter to the inlet.
Carbon airbox high & low-pressure zones channel low-temp airflow quickly to the engine while protecting it from radiant engine heat.

Integrated Engineering IE Audi B9 SQ5 3.0T Carbon Fibre Intake System - ML Performance US

Installation

The installation process is quick and straightforward using basic hand tools. The entire airbox system utilizes factory-style mounts that ensure a perfect and hassle-free fit.Â

Intake install time: 1 hour or less

Compatibility

AUDI SQ5Â 2018+ (B9)Â 3.0T Turbocharged

PartÂ Number

IEINCZ1
